Reznor ADFH Parts Manuals User Manual
Page 15
Form P-ADF, P/N 270068 R1, Page 15
CODE 134 -
Bearing
supports for
Size 1200 with
a 15-20HP
Motor are part
of the blower.
CODE 134 - Triangular Bearing Support - Optional with
1/2 - 5HP motor; standard with 7-1/2-10HP motor
Left Bearing Support Assy
112971
Right Bearing Support Assy
112972
Pillowblock Bearing
See
CODE 135.
90° Grease Fitting
(2)
195834
1/2-13 x 2" Cap Screw
(4)
111304
1/2-13 Nut
(4)
111305
1/2 Lockwasher
(4)
111306
1/4-20 Cap Screw
(6)
16246
1/4-20 Lock Nut
(6)
10650
CODE Description
Model / Size
ADF300
ADFH300
ADF500
ADFH500
ADF/ADFH700
ADF/ADFH1200
130 Adapter Back Assembly
Horizontal Discharge
--
--
--
--
122822
130A Adapter Back Top
--
--
--
--
122084
130B Adapter Back Bottom
--
--
--
--
120391
130C Adapter Back Center Section
--
--
--
--
122083
130D Adapter Back Left End
--
--
--
--
120039
130E Adapater Back Right End
--
--
--
--
120040
130F Adapter Back Left Rear Sctn
--
--
--
--
122095
160617
130G Adapter Back Right Rear Sctn
--
--
--
--
122085
160618
131 Vertical Blower Support - Left
106299
132 Vertical Blower Support - Right
106943
133
Standard BLOWER,
Class I (Option A1)
w/1/2 - 5 HP mtr
1360, A12x12AC
100658, A15x11ACD
(2)
112606, A12x12AC
(2)
14469, A15x11A
(includes wheel, housing, 1" shaft, bearings
& bearing support)
(1", includes blower
wheel and housing)
(1-3/16", includes blower
wheel and housing)
BLOWER, Class II
(Option A2) - (includes
wheel and housing)
w/1/2 - 5HP mtr
123212
A12x12, 1-3/16"
14469
A15x11A, 1-3/16"
(2)
123212
A12x12, 1-3/16"
(2)
14469
A15x11A, 1-3/16"
w/7-1/2 - 10HP
mtr
--
(7-1/2 HP only) 123212
A12x12, 1-3/16"
--
14469
A15x11A, 1-3/16"
(2)
123212
A12x12, 1-3/16"
(2)
14469
A15x11A, 1-3/16"
w/15-20HP mtr
--
--
--
--
--
106937 Right; 106938 Left (drive
side) (1-7/16", includes blower,
housing, & bearing supports)
134
Standard Blower
BEARING SUPPORT,
Class I Blower
w/1/2 - 5HP mtr
--
--
--
--
(3)
122826
(3)
24233
BEARING SUPPORT,
Class II Blower
w/1/2 - 5HP mtr
(2)
123213
112972 Right; 112971 Left
(2)
123213
112972 Right; 112971 Left
w/7-1/2 - 10HP
mtr
--
(2)
123213
--
112972 Right;
112971 Left
(2)
123213
112972 Right; 112971 Left
w/15 - 20HP mtr
--
--
--
--
--
(part of the blower)
Retaining Clip,
P/N 112570
3/8” Bolt,
P/N 32253
Star Washer,
P/N 112571
Motor
Mounting
Base
Retaining Clip,
P/N 112572
Star Washer,
P/N 112573
5/16” Bolt,
P/N 16247
Motor
Mounting
Base
Motor Mounting Bolts (3/8" and 5/16") - For CODE 137
for 7-1/2 - 20 HP Motor
CODE Description
Model / Size
ADF300
ADFH300
ADF500
ADFH500
ADF/ADFH700
ADF/ADFH1200
135
BEARINGS, Class I
Standard Blower
1/2 - 5HP motor
(2)
10437, #SRC-16-1-1"
(3)
10437
(3)
14474, 1-3/16
BEARINGS, Class II
Blower
1/2 - 5HP motor
(2)
123216, 1-3/16"
(2)
112973, 1-3/16"
(2)
123216, 1-3/16"
(2)
112973, 1-3/16
7-1/2 - 10HP mtr
--
(2)
123216
--
(2)
112973, 1-3/16"
(2)
123216, 1-3/16"
(2)
112973, 1-3/16
15 - 20HP motor
--
--
--
--
--
(2)
106942, 1-7/16
136
Blower SHAFT, Class
I Standard Blower
1/2 - 5HP motor
11303, 1" x 19"
122827, 1" x 50"
13589, 1-3/16" x 48"
Blower SHAFT, Class
II Blower
1/2 - 5HP motor
122994, 1-3/16" x 23"
122796, 1-3/16x50
13589, 1-3/16" x 48"
7-1/2 - 10HP mtr
--
122994
--
122994, 1-3/16" x 23"
122796, 1-3/16x50
13589, 1-3/16" x 48"
15 - 20HP motor
--
--
--
--
--
106941, 1-7/16" x 53"
137
Motor Mounting Plate Assy
for 1/2 - 5 HP Mtrs 122828
Components:
Washers 5/16 Flat
(16)
1087
Nut Hex 5/16 18 Keps
(12)
6554
Rod Bolt 5/16-18 C-135a Zinc
(2)
12489
Blower Motor Mounting Plate
12578
Cap Screw 5/16 In. X 3/4 In.
(10)
16247
Screw Cap 5/16 X 1-1/2
(2)
16248
Motor Base Support
(2)
120684
Motor Mounting Plate Support, Left
12576
Motor Mounting Plate Support, Right
12577
Motor Mounting Base
for 7-1/2 - 20 HP
Motors (hardware in illustration on the right)
106295
