Reznor ADFH Parts Manuals - Manual (Page 7)

Form P-ADF, P/N 270068 R1, Page 7
(continued)
CODE 45 - Motor
Shaft volt ph Service
Factor
Power
Factor
EFF.
CODE 47A - Starter
Contactor w/24 volt coil
CODE 47B - Starter Overload
CODE 46 - Motor
Contactor (Option AN2)
Type hp P/N Mfr No. Frame fla Mfr No. P/N min max GE # P/N Mfr No. P/N
Open
7.5
105855 AO-E300 213T 19.4 1-3/8" 240 3 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
Open 105855 AO-E300 213T 9.7 1-3/8" 480 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
Open 158164 AO-E324 S213T 7.8 1-3/8" 575 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
Open
10
105830 AO-V303 S215T 42.0 1-3/8" 208 1 CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
Open 105830 AO-V303 S215T 38.0 1-3/8" 230 1 CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
Open 105858 AO-E301 215T 31.0 1-3/8" 208 3 CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
Open 105858 AO-E301 215T 26.0 1-3/8" 240 3 CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
Open 105858 AO-E301 215T 13.0 1-3/8" 480 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
Open 158163 AO-E325 S215T 10.4 1-3/8" 575 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
Open
15
142287 B-FM2513T-8-F2 254T 43.1 1-5/8" 208 3 CL06A311M-1 203687 42.0 55.0 RTA2-G 151202 ============ ======
Open 142288 BALD-FM2513T-F2 254T 39.0 1-5/8" 240 3 CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
Open 142288 BALD-FM2513T-F2 254T 19.5 1-5/8" 480 3 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
Open 142289 B-EFM2513T-5-F2 254T 16.0 1-5/8" 575 3 CL02A310T-1 151277 14.5 18.0 RTA1-S 151196 ============ ======
Open
20
142295 B-FM2515T-8-F2 256T 58.7 1-5/8" 208 3 1.2 80 88.5% CL07A311M-1 203793 54.0 65.0 RTA2-H 151203 ============ ======
Open 142296 BAL-FM2515T-F2 256T 53.0 1-5/8" 240 3 1.2 81 88.5% CL07A311M-1 203793 42.0 55.0 RTA2-G 151202 ============ ======
Open 142296 BAL-FM2515T-F2 256T 26.5 1-5/8" 480 3 1.2 81 88.5% CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
Open 142297 B-FM2515T-5-F2 256T 21.2 1-5/8" 575 3 1.2 80 88.5% CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
TEFC
1/2
159184 AO-C613 J56 7.2 5/8" 120 1 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 HCC-3XQOICY 216386
TEFC 159184 AO-C613 J56 3.5 5/8" 208 1 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 HCC-3XQOICY 216386
TEFC 159184 AO-C613 J56 3.6 5/8" 240 1 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 HCC-3XQOICY 216386
TEFC 16077 AO-H274 H56 2.3 5/8" 208 3 1 59.5 74.8% CL00A310T-1 151275 1.8 2.7 RTA1-J 151189 HCC-3XQOICY 216386
TEFC 16077 AO-H274 H56 2.0 5/8" 240 3 1 59.5 74.8% CL00A310T-1 151275 1.8 2.7 RTA1-J 151189 HCC-3XQOICY 216386
TEFC 16077 AO-H274 H56 1.0 5/8" 480 3 1 59.5 74.8% CL00A310T-1 151275 0.7 1.1 RTA1-F 151186 HCC-3XQOICY 216386
TEFC 105568 AO-H276 J56 0.7 5/8" 575 3 1.2 76.4 77% CL00A310T-1 151275 0.7 1.1 RTA1-F 151186 ============ ======
TEFC
3/4
115860 AO-F353 F56 11.0 5/8" 120 1 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 HCC-3XQOICY 216386
TEFC 115860 AO-F353 F56 5.4 5/8" 208 1 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 159184 AO-F353 F56 5.5 5/8" 240 1 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 20371 AO-H580 KA56 2.0 5/8" 208 3 1 73.5 81.1% CL00A310T-1 151275 1.8 2.7 RTA1-J 151189 HCC-3XQOICY 216386
TEFC 20371 AO-H580 KA56 2.2 5/8" 240 3 1 73.5 81.1% CL00A310T-1 151275 1.8 2.7 RTA1-J 151189 HCC-3XQOICY 216386
TEFC 20371 AO-H580 KA56 1.1 5/8" 480 3 1 73.5 81.1% CL00A310T-1 151275 1.0 1.5 RTA1-G 151187 HCC-3XQOICY 216386
TEFC 105569 AO-H461 L56 0.8 5/8" 575 3 1.2 78.3 82% CL00A310T-1 151275 0.7 1.1 RTA1-F 151186 ============ ======
TEFC
1
174993 AO-159105 L56 12.0 5/8" 120 1 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 HCC-3XQOICY ======
TEFC 174993 AO-159105 L56 6.2 5/8" 208 1 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 174993 AO-159105 L56 6.0 5/8" 240 1 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 16080 AO-H524 J56 3.3 5/8" 208 3 1 74.4 80.2% CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 HCC-3XQOICY 216386
TEFC 16080 AO-H524 J56 3.4 5/8" 240 3 1 74.4 80.2% CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 HCC-3XQOICY 216386
TEFC 16080 AO-H524 J56 1.7 5/8" 480 3 1 74.4 80.2% CL00A310T-1 151275 1.3 1.9 RTA1-K 151188 HCC-3XQOICY 216386
TEFC 105570 AO-H525 H56 1.4 5/8" 575 3 1.2 71.6 80.4% CL00A310T-1 151275 1.0 1.5 RTA1-H 151187 ============ ======
TEFC
1.5
94347 AO-311P402 TK56H 16.4 5/8" 120 1 CL02A310T-1 151277 14.5 18.0 RTA1-S 151196 HCC-3XQOICY 216386
TEFC 94347 AO-311P402 TK56H 9.5 5/8" 208 1 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 HCC-3XQOICY 216386
TEFC 94347 AO-311P402 TK56H 8.2 5/8" 240 1 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 HCC-3XQOICY 216386
TEFC 101286 AO-H535 L56H 4.3 5/8" 208 3 1 80.9 82.4% CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 101286 AO-H535 L56H 4.4 5/8" 240 3 1 80.9 82.4% CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 HCC-3XQOICY 216386
TEFC 101286 AO-H535 L56H 2.2 5/8" 480 3 1 80.9 82.4% CL00A310T-1 151275 1.8 2.7 RTA1-J 151189 HCC-3XQOICY 216386
TEFC 105665 AO-E127 M145T 1.6 7/8" 575 3 1.2 85.7 84% CL00A310T-1 151275 1.3 1.9 RTA1-H 151188 ============ ======
TEFC
2
105572 AO-K200 F182T 24 1-1/8" 120 1 CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
TEFC 205881 L3516TM 56HZ 8.3 7/8" 240 1 1.2 99 78% CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 HCC-3XQOICY 216386
TEFC 158165 AO-E166 145T 7.0 7/8" 208 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
TEFC 158165 AO-E166 145T 5.8 7/8" 240 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
TEFC 158165 AO-E166 145T 2.9 7/8" 480 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
TEFC 158166 AO-E169 145T 2.3 7/8" 575 3 CL00A310T-1 151275 1.9 2.7 RTA1-J 151189 ============ ======
TEFC
3
111564 AO-K222 F184T 30.0 1-1/8" 120 1 CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
TEFC 111564 AO-K222 F184T 15.0 1-1/8" 240 1 CL02A310T-1 151277 14.5 18.0 RTA1-S 151196 ============ ======
TEFC 159330 B - M3559T 145T 7.9 7/8" 208 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
TEFC 159330 B - M3559T 145T 7.2 7/8" 240 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
TEFC 159330 B - M3559T 145T 3.6 7/8" 480 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
TEFC 111571 B-M3559T-5 145T 3 7/8" 575 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
TEFC
5
111567 AO-K223 F184T 20.2 1-1/8" 240 1 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
TEFC 155048 AO-E241 184T 16 1-1/8" 208 3 CL02A310T-1 151277 14.5 18.0 RTA1-S 151196 ============ ======
TEFC 155048 AO-E241 184T 12 1-1/8" 240 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
TEFC 155048 AO-E241 184T 6 1-1/8" 480 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
TEFC 158170 AO-E273 184T 4.8 1-1/8" 575 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
TEFC
7.5
105842 AO-K305 F215T 34 1-3/8" 240 1 CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
TEFC 158171 AO-E356 213T 24 1-3/8" 208 3 CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
TEFC 158171 AO-E356 213T 19 1-3/8" 240 3 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
TEFC 158171 AO-E356 213T 9.5 1-3/8" 480 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
TEFC 158172 AO-E364 213T 7.6 1-3/8" 575 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
