S p e c i f i c a t i o n s : D C a r o u s e l
( c o n t i n u e d )
7/16 inches {1.1 cm}
diameter
4 inches
{10.2 cm}
square
1 inch {2.5 cm}
diameter
3 inches {7.6 cm} square
6 inches
{15.2 cm}
square
7/16 inches {1.1 cm}
diameter
5 inches {12.7 cm} square
2 inches {5.1 cm}
diameter
Standard Base Plate
IB02
Optional Base Plate
IB01
(for mounting CH10
and CH14 hoppers
independent of dryer
only)
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
OPTIONAL HOPPERS AND MOUNTING BRACKET
MOUNTING PATTERNS
▲
▲
HOPPER MODEL
CH10-0.5
CH10-1
CH10-1.5
CH14-2
CH14-3
CH14-4
Hopper / Mounting Frame Dimensions inches {cm}
A - Insulated hopper diameter
12.5 {13.8}
12.5 {31.8}
12.5 {31.8}
17 {43.2}
17 {43.2}
17 {43.2}
B - Overall height
32 {81.3}
43 {109.2}
54 {137.2}
45 {114.3}
56 {142.2}
67 {170.2}
C - Base plate, square
7.5 {19}
7.5 {19}
7.5 {19}
6.5 {16.5}
6.5 {16.5}
6.5 {16.5}
D - Width with insulated hopper
39 {99.1}
39 {99.1}
39 {99.1}
41 {104.1}
41 {104.1}
41 {104.1}
Volume ft
3
{liters}
0.5 {9.4}
1 {28.3}
1.5 {42.5}
2 {56.6}
3 {85}
4 {113.2}
Capacity lb {kg} @40 lb/ft
3
20 {9.0}
40 {18.1}
60 {27.2}
80 {36.3}
120 {54.4}
160 {72.5}
Mounting Frame Weight lb {kg}
30 {13.6}
30 {13.6}
30 {13.6}
35 {15.9}
35 {15.9}
35 {15.9}
Hopper Weight lb {kg}
Insulated
40 {18.1}
50 {22.7}
70 {31.7}
80 {36.32}
95 {43.1}
110 {48.9}
HOPPER MODEL
CH18-4
CH18-6
CH24-8
CH24-12
CH24-15
Hopper / Mounting Frame Dimensions inches {cm}
A - Insulated hopper diameter
21 {53.3}
21 {53.3}
27 {68.58}
27 {68.58}
27 {68.58}
B - Overall height
48 {121.9}
68 {172.7}
64 {162.6}
79 {200.7}
90 {228.6}
C - Base plate, square
6.5 {16.5}
6.5 {16.5}
6.5 {16.5}
6.5 {16.5}
6.5 {16.5}
D - Width
47.63 {121.0}
47.63 {121.0}
47.63 {121.0}
50.63 {128.6}
50.63 {128.6}
Volume ft
3
{liters}
4 {113.3}
6 {169.9}
8 {226.5}
12 {339.8}
15 {424.8}
Capacity lb {kg} @40 lb/ft
3
160 {72.5}
240 {108.9}
320 {145.1}
480 {217.7}
600 {272.2}
Mounting Frame Weight lb {kg}
50 {22.7}
50 {22.7}
70 {31.7}
70 {31.7}
70 {31.7}
Hopper Weight lb {kg}
Insulated
145 {66}
165 {75}
210 {95}
235 {107}
255 {116}
D
B
A
C
