UG_6612_ 017 6612_OMU_S2+2_URT_V1_14 Firmware Description Document
Rev. 1.0 55
Table 11: MPU Input Summary Chart
Voltage A0 Vmax
Current - Outlet 1 A1 Imin (Creep A) - Outlet1
A2 Imax (A) - Outlet1
Current - Outlet 2 A3 Imin (Creep B) - Outlet2
A4 Imax (B) - Outlet2
Unused A5 Unused
Temperature A6 TEMPERATURE NOMINAL
A7 Reserved
A8 PPMC
A9 PPMC2
Cost AA Cost per KWh
AB Cost Unit string
Relay Configuration AC Polarity, Latch type
AD Sequence Delay
AE Energize Delay
AF Denergize Delay
B0 -BC Unused
Misc. Config BD Configuration
Unused BE Unused
BF Tolerance on Phase Calibration
Quick Calibration Parameters C0 Calibration Type
C1 Calibration Voltage (Target)
C2 Calibration Current (Target)
C3 Calibration Phase
C4 Tolerance on Voltage Calibration
C5 Tolerance on Current Calibration
C6 Average Count for Voltage
C7 Average Count for Current
C8 Max Iterations for Voltage
C9 Max Iterations for Current
CA Tolerance on Watts Calibration
CB Average Count for Watts
CC Max Iterations for Watts
CD Calibration WRATE
CE Calibration Temperature
CF Calibration Watts (Target)
Temperature D0 Min Temperature Alarm Threshold
D1 Max Temperature Alarm Threshold
Frequency D2 Min Frequency Alarm Threshold
D3 Max Frequency Alarm Threshold
