6612_OMU_S2+2_URT_V1_14 Firmware Description Document UG_6612_017
38 Rev. 1.0
Table 7 lists the wideband measurement outputs for both outlets combined (Outlet 1 + Outlet 2).
Table 7: Combined Outlets MPU Outputs for Wideband Method
Output
Location
(hex)
LSB Comment Example
Watts T 90 mW
Active power measurement (per
second) on both outlets.
Note: Duplicate of address 0x80
(see Table 6 ).
If 120 W atts are measured on both
outlets
)90?
Returns:
+120.000
Wh T 91 mWh
Active accumulated energy
measurement (per hour) on both
outlets.
Note: Duplicate of address 0x81
(see Table 6 ).
If 120 W h are measured on
Outlet 2
)91?
Returns:
+120.000
Total Cost T 92 mUnits
Total Cost of Wh for both outlets.
Note: Duplicate of address 0x82
(see Table 6 ).
If the total cost is 102.536 units on
both outlets
)92?
+102.536
Irms_wb T 93 mArms
Combined outlet wideband rms
current measurement.
If wideband current measured on
both outlets is 12 Amps
)93?
Returns:
+12.000
VARs_wb T 94 mW
Combined outlet wideband reactive
power measurement (per second).
If wideband 120 VARs are
measured on both outlets
)94?
Returns:
+120.000
VAs_wb T 95 mW
Combined outlet wideband
apparent power measurement (per
second).
If wideband 120 VAs are measured
on both outlets
)95?
Returns:
+120.000
Irms_wb T
Overcurrent
Event
Count
96
Counter increments on each edge
event.
If four wideband over current
events have occurred on Outlet 1
and Outlet 2:
)96?
Returns:
+4
Reserved 97 – Reserved Reserved
Watts T Min 98 mW
Minimum combined outlet active
power measured (per second)
Note: Duplicate of address 0x88
(see Table 6 ).
If the minimum power measured on
both outlets is 80 Watts
)98?
Returns:
+80.000
Watts T
Max
99 mW
Maximum combined outlet active
power measured (per second)
Note: Duplicate of address 0x89
(see Table 6 ).
If the maximum power measured
on both outlets is 200 Watts
)99?
Returns:
+200.000
Irms_wb T
Min
9A mArms
Minimum combined outlet
wideband rms current measured.
If the smallest wideband current
measured on both outlets is 1 Amp
)9A?
Returns:
+1.000
