6612_OMU_S2+2_URT_V1_14 Firmware Description Document UG_6612_017
46 Rev. 1.0
MPU
Parameter
Location
(hex)
LSB Default Comment Example
PFB_wb_Neg
Threshold
E2 – -0.700
Wideband Power Factor Negative
Threshold for Outlet 2. A less
negative wideband power factor
than this threshold will set an
alarm (bit 17 of the Alarm Status
Register). Only available if )F2 bit
2 is set to 1.
If the negative wideband
power factor threshold on
Outlet 2 is to be changed
from the default to -0.6 then
set as follows:
)E2=-0.600
PFB_wb_Pos
Threshold
E3 – +0.700
Wideband Power Factor Positive
Threshold for Outlet 2. A positive
wideband power factor less than
this threshold will set an alarm (bit
18 of the Alarm Status Register).
If the positive wideband
power factor threshold on
Outlet 2 is to be changed
from the default to +0.6
then set as follows:
)E3=+0.600
Peak I
Total_nb
Alarm
Threshold
E4 mArms +20.000
Maximum Narrowband Current
measured on Outlet 1 plus Outlet
2 above which a flag must be set
(bit 19 of the Alarm Status
Register).
If the narrowband peak
current threshold on Outlet
1 plus Outlet 2 is to be
changed from the default
value of 20 Amps to 30
Amps then set as follows:
)E4=+30.000
Peak I
Total_wb
Alarm
Threshold
E5 mArms +20.000
Maximum Wideband Current
measured on Outlet 1 plus Outlet
2 above which a flag must be set
(bit 20 of the Alarm Status
Register).
If the wideband peak
current threshold on Outlet
1 plus Outlet 2 is to be
changed from the default
value of 20 Amps to 30
Amps then set as follows:
)E5=+30.000
Alarm
Mask_Reg
E6 – 00801FFF
Alarm mask for bits in the Alarm
Status register. A “0” masks the
alarm from the register bit.
If bits 0 and 1 are to be
masked then set as follows:
>)E6=FFFFFFFC
Alarm
Mask_DIO
E7 – 00801FFF
Alarm mask for an alarm pin
(DIO20). A “0” masks the alarm
from DIO20
Control Relay F0 – 0
Bit 1 (Relay for Outlet 2)
0 = DIO19 = 0
1 = DIO19 =1
Bit 0 (Relay for Outlet 1)
0 = DIO7 = 0
1 = DIO7 = 1
Note: AC[1] = 1 inverts the bits
above.
Min/Max
Control
F1 – 0
BIT1 – 1 Start/Stop MIN/MAX
recording.
1 = Start
0 = Stop
BIT0 – 1 Reset MIN/MAX
registers before recording. Bit
autoclears.
Reset & Start MIN/MAX
recording.
)AC=11
Stop MIN/MAX recording
)AC=0x
