UG_6612_ 017 6612_OMU_S2+2_URT_V1_14 Firmware Description Document
Rev. 1.0 13
4.5.1.2 CALW Command
To use the CALW command, enter the following:
>CALW
The response is:
TCal OK
VCal OK
WCal 0 OK
>
The device will calibrate the temperature, calibrate the voltage, and finally calibrate the power and save
all values to flash.
The commands are summarized in the table below:
CALx Complete Calibration Commands
Description: Allows the user to Calibrate the IC.
Usage: CAL Calibrates temperature, then voltage,
and finally current for Outlet 1.
CAL2 Calibrates temperature, then voltage,
and finally current for Outlet 2.
CAL3 Calibrates temperature, then voltage,
and finally current for both Outlet1 and
Outlet 2.
CALW Calibrates temperature, then voltage,
and finally power for Outlet 1.
CALW2 Calibrates temperature, then voltage,
and finally power for Outlet 2.
CALW3 Calibrates temperature, then voltage,
and finally power for both Outlet1 and
Outlet 2.
