6612_OMU_S2+2_URT_V1_14 Firmware Description Document

Rev. 1.0

39

Output

Location

(hex)

LSB

Comment

Example

Irms_wb T

Max

9B

mArms

Maximum combined outlet

wideband rms current measured.

If the largest wideband current
measured on both outlets is 30

Amps

)9B?

Returns:

+30.000

VARs_wb T

Min

9C

mW

Minimum combined outlet

wideband reactive power

measured (per second).

If the largest VARs measured on

both outlets is 80 VARs

)9C?

Returns:

+80.000

VARs_wb T

Max

9D

mW

Maximum combined outlet

wideband reactive power

measured (per second).

If the largest VARs measured on

both outlets is 300 VARs

)9D?

Returns:

+300.000

VAs_wb T

Min

9E

mW

Minimum combined outlet

wideband apparent power

measured (per second).

If the smallest VAs measured on

both outlets is 80 VARs

)9E?

Returns:

+80.000

VAs_wb T

Max

9F

mW

Maximum combined outlet

wideband apparent power

measured (per second).

If the largest VAs measured on

both outlets is 300 VARs

)9F?

Returns:

+300.000
