6612_OMU_S2+2_URT_V1_14 Firmware Description Document

UG_6612_017

48

Rev. 1.0

6.2 CE Parameters

Table 9 lists the CE parameters that the Firmware 6612_OMU_S2+2_URT_V1_14 has set. The user
does not need to alter any of these parameters as they are automatically set by Calibration Commands.

Table 9: CE Parameters

CE

Parameter

Location(

hex)

LSB

Default

Comment

Example

CAL IA

08

16384 is

the default

and is a

gain of 1.

32767 is

max giving

a gain of

2.

+13873

Gain constant for

IA input.

If current on channel A is low by 1%

scale the nominal number, 16384 by

1/(1-0.01). Number to be entered would

be 16549:

]08=+16549

If current on channel A is high by 1%

scale the nominal number, 16384 by

1/(1+0.01). Number to be entered

would be 16222:

]08=+16222

CAL IB

09

16384 is

the default

and is a

gain of 1.

32767 is

max giving

a gain of

2.

+13873

Gain constant for

IB input.

If current on channel B is low by 1%

scale the nominal number, 16384 by

1/(1-0.01). Number to be entered would

be 16549:

]09=+16549

If current on channel A is high by 1%

scale the nominal number, 16384 by

1/(1+0.01). Number to be entered

would be 16222:

]09=+16222

CAL VA

0A

16384 is

the default

and is a

gain of 1.

32767 is

max giving

a gain of

2.

+13024

Gain constant for

VA input.

If voltage on channel A is low by 1%

scale the nominal number, 16384 by

1/(1-0.01). Number to be entered would

be 16549:

]0A=+16549

If current on channel A is high by 1%

scale the nominal number, 16384 by

1/(1+0.01). Number to be entered

would be 16222:

]0A=+16222

CAL VB

0B

16384 is

the default

and is a

gain of 1.

32767 is

max giving

a gain of

2.

+13024

Gain constant for

VB input.

If voltage on channel B is low by 1%

scale the nominal number, 16384 by

1/(1-0.01). Number to be entered would

be 16549:

]0B=+16549

If current on channel A is high by 1%

scale the nominal number, 16384 by

1/(1+0.01). Number to be entered

would be 16222:

]0B=+16222

PHASE_

ADJ_IA

0C

-16384

PHASE_A
DJ_IA

+16384

0

Outlet 1 Phase

adjustment =15 *

PHASE_ADJ_IA *

2

-14

(degrees)

No adjustment should be necessary

when using current shunts.

PHASE_

ADJ_IB

0D

-16384

PHASE_A
DJ_IB

+16384

0

Outlet 2 Phase

adjustment =15 *

PHASE_ADJ_IB *

2

-14

(degrees)

No adjustment should be necessary

when using current shunts.
