UG_6612_ 017 6612_OMU_S2+2_URT_V1_14 Firmware Description Document
Rev. 1.0 31
Output
Location
(hex)
LSB Comment Example
Irms_nb B
Min
54 mArms
Outlet 2 minimum narrowband rms
current measured.
If the smallest narrowband current
measured on Outlet 2 is 1 Amp
)54?
Returns:
+1.000
Irms_nb B
Max
55 mArms
Outlet 2 maximum narrowband rms
current measured.
If the largest narrowband current
measured on Outlet 2 is 30 Amps
)55?
Returns:
+30.000
VARs_nb B
Min
56 mW
Outlet 2 minimum narrowband
reactive power measured (per
second).
If the largest VARs measured on
Outlet 2 is 80 VARs
)56?
Returns:
+80.000
VARs_nb B
Max
57 mW
Outlet 2 maximum narrowband
reactive power measured (per
second).
If the largest narrowband VARs
measured on Outlet 2 is
300 VARs
)57?
Returns:
+300.000
VAs_nb B
Min
58 mW
Outlet 2 minimum narrowband
apparent power measured (per
second)
If the smallest narrowband VAs
measured on Outlet 2 is 80 VARs
)58?
Returns:
+80.000
VAs_nb B
Max
59 mW
Outlet 2 maximum narrowband
apparent power measured (per
second).
If the largest narrowband VAs
measured on Outlet 2 is
300 VARs
)59?
Returns:
+300.000
Power
Factor_nb B
Min
5A –
Outlet 2 minimum narrowband
power factor measured. Minimum
is defined as the most negative or
least positive number.
If minimum narrowband power
factor measured on Outlet 2 is
-0.6
)5A? Returns:
-0.600
Power
Factor_nb B
Max
5B –
Outlet 2 maximum narrowband
power factor measured. Maximum
is defined as the most positive or
least negative number.
If maximum narrowband power
factor measured on Outlet 2 is 0.9
)5B? Returns:
+0.900
Phase
Angle_nb B
Min
5C –
Outlet 2 minimum narrowband
phase angle measured.
If the minimum narrowband phase
angle measured on Outlet 2 is 10
degrees
)5C?
Returns:
+10.000
Phase
Angle_nb B
Max
5D –
Outlet 2 maximum narrowband
phase angle measured.
If the maximum narrowband phase
angle measured on Outlet 2 is 70
degrees
)5D?
Returns:
+70.000
Reserved 5E – Reserved Reserved
Reserved 5F – Reserved Reserved
