6612_OMU_S2+2_URT_V1_14 Firmware Description Document UG_6612_017
34 Rev. 1.0
Output
Location
(hex)
LSB Comment Example
Irms_wb B 6A mArms
Outlet 2 wideband rms current
measurement.
If wideband current measured on
Outlet 2 is 12 Amps
)6A?
Returns:
+12.000
VARs_wb B 6B mW
Outlet 2 wideband reactive power
measurement (per second).
If wideband 120 VARs are
measured on Outlet 2
)6B?
Returns:
+120.000
VAs_wb B 6C mW
Outlet 2 wideband apparent power
measurement (per second).
If wideband 120 VAs are
measured on Outlet 2
)6C?
Returns:
+120.000
Power
Factor_wb B
6D –
Outlet 2 wideband power factor.
The output will be between -0.950
and 1.000. Positive power factor is
defined as current lagging voltage
(inductive). Negative power factor
is defined as voltage lagging
current (capacitive).
If the wideband power factor on
Outlet 2 is 0.95
)6D?
Returns:
+0.950
Phase
Angle_wb B
6E mDegrees
Outlet 2 wideband phase angle.
The output will be between
180.000 and -180.000.
If the wideband phase angle
measured on Outlet 2 is
60 degrees
)6E?
Returns:
+60.000
Reserved 6F – Reserved Reserved
Vrms A Min 70 mV
Minimum Vrms measured
Note: Duplicate of address 0x10
(see Table 2 ).
If the minimum line voltage
measured was 105 V
)70
Returns:
+15.000
Vrms A Max 71 mV
Maximum Vrms measured
Note: Duplicate of address 0x11
(see Table 2 ).
If the maximum line voltage
measured was 130 V
)71
Returns:
+130.000
Watts B Min 72 mW
Minimum Outlet 2 active power
measured (per second)
Note: Duplicate of address 0x52
(see Table 4 ).
If the minimum power measured
on Outlet 2 is 80 Watts
)72?
Returns:
+80.000
Watts B Max 73 mW
Maximum Outlet 2 active power
measured (per second)
Note: Duplicate of address 0x53
(see Table 4 ).
If the maximum power measured
on Outlet 2 is 200 Watts
)73?
Returns:
+200.000
Irms_wb B
Min
74 mArms
Outlet 2 minimum wideband rms
current measured.
If the smallest wideband current
measured on Outlet 2 is 1 Amp
)74?
Returns:
+1.000
