KGUARD Security OT1601 - Manual (Page 50)

ENGLISH
Chapter 4: Using the DVR
50
DVR User’s Manual
4.5.2 Other Alarm Settings
For 16-channel DVRs with a connected alarm device, do the following to set up the alarm settings:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > ALARM, select the Alarm tab.
3
Modify the necessary settings:
Menu item Description
Alarm In Select the channel that will trigger the alarm.
Alarm Type Select the alarm type: NO (Normal-Open), NC (Normal-Close), or OFF.
Alarm Out If an alarm device is connected, check the box to make the device sound the alarm when
triggered.
Dwell Time Select the alarm sound duration of the I/O alarm device (10S/20S/40S/60S) then check to
apply the setting to each alarm type.
Show
Message
Check the box to display a message on screen when the alarm is triggered.
Buzzer Set the buzzer duration when the alarm is triggered (Off/10 S/20 S/40 S/60 S).
To disable buzzer, select Off.
Send Email Check to enable email alarm notification. If the function is enabled, the system will send
the alarm images to the specified email address. See
“4.4.4 Email Settings” on page 46 .
Full Screen Check the box to enable this function. If this function is enabled and the alarm is triggered,
the corresponding channel will be displayed in full screen. Select the screen display
duration (1 S/3 S/5 S/7 S/10 S)
Record
Channel Check the box to enable recording and then select the channels to record when the alarm
is triggered.
Post
Recording
Select the post-recording duration.
4
Click Apply.
5
When data saving is complete, click OK.
« TIP »
• To copy the current settings to other channels, select the channel, then click Copy.
• To revert to the default alarm settings, click Default.
6
When data saving is complete, click OK.
