ENGLISH
Chapter 4: Using the DVR
48
DVR User’s Manual
4.5 Setting Alarms
On the alarm menu, you can configure the motion detection and the alarm notification settings.
4.5.1 Motion Detection Alarm Settings
For added security, enable the motion detection feature. When motion is detected on a selected area, the DVR issues
an alarm notification. To set the motion detection alarm, do the following:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > ALARM.
3
Modify the necessary settings:
Menu item Description
Channel Select the channel to set motion detection.
Enable Select Enable to enable motion detection alarm for the channel.
Area Click Setup to select the area for motion detection alarm. See “Set Motion Detection Area”
on page 49.
Sensitivity Select the motion detection sensitivity rate. Options are : 1~8, wherein “8” is the most
sensitive and “1” is the least sensitive.
Show
Message
Check the box to display a message on screen when the alarm is triggered.
Buzzer Set the buzzer duration when motion is detected (Off/10 S/20 S/40 S/60 S).
To disable buzzer, select Off.
Send Email Check to enable email alarm notification. If the function is enabled, the system will send
the alarm images to the specified email address. See
“4.4.4 Email Settings” on page 46 .
Full Screen Check the box to enable this function. If this function is enabled and the alarm is triggered,
the corresponding channel will be displayed in full screen. Select the screen display
duration (1 S/3 S/5 S/7 S/10 S)
Record
Channel Check the box to enable recording and then select the channels to record when the alarm
is triggered.
Post
Recording
Select the post-recording duration.
4
Click Apply.
5
When data saving is complete, click OK.
« TIP »
• To copy the current settings to other channels, select the channel, then click Copy.
• To revert to the default alarm settings, click Default.
6
When data saving is complete, click OK.
