Chapter 2: Installation
DVR User’s Manual
15
2.3 Connecting to Monitors
The preview screen can be displayed on monitors via BNC, VGA or HDMI connection.
2.3.1 BNC Connection
Connect the video output of the DVR to the monitor via BNC connector as shown.
2.3.2 VGA Connection
Connect the video output of the DVR to the monitor via VGA connector as shown.
