IQ3 Data Logger Dash Installation Manual
55
Map Select Dialog Window
The Map Select Dialog Window is designed to assist the user in selecting previously created and
saved GPS Track Maps. After extended use of the data system, it is possible to have quite a
large collection of saved maps. However, the Racepak engineers have created a unique way to
provide a limited number of maps for selection. Upon download of a new run, the Datalink II
software reviews the location of the vehicle, relative to GPS data. Then, only previously saved
maps that are located within a five mile radius of the newly downloaded run, will be displayed
for selection.
For a run at a new location that does not
detect any previously saved track maps
within that five mile radius, the above Create
New message will appear in the Map Select
Dialog Window. Since these instructions
assume this is the first download for a new
system:
1. Select Next
2. The Weather dialog box will be
presented. If desired, enter the current weather conditions. If not desired, this
information can be entered at a later date, then select OK.
