IQ3 Data Logger Dash Installation Manual
28
Downloaded Data : Stored IQ3 data is downloaded to the user’s PC by means of the IQ3
microSD memory card. Before the data can be opened into the DataLink software, it must first
pass “through” the Configuration file.
Configuration File : The IQ3 Configuration file, contained within the DataLink program, is
automatically loaded with the installation of the DataLink software. The Configuration file
contains all the information necessary to convert the raw data saved on the memory card into a
format that allows the file to be opened in the DataLink software.
The configuration file is a “template” for all downloaded data, containing channel names,
calibration values and scaling values, along with programming features such as the start data
logging channel, etc.
DataLink Software : The Datalink II software provides the ability to open and graph data
contained in a runfile. The DataLink is software is generic in nature, in that it does not store
information related to the data logger setup. Instead, the software contains settings relevant to
the graphing of data and the user’s PC setup.
PC Requirements
PC Hardware Requirements
• USB Port
• Serial Communications Port or USB to Serial Port Adapter
• CD/DVD drive
• 3 Button Mouse
Note: The use of a mouse with a center button is highly recommended
If your PC does not have a CD drive please contact Racepak and request the optional DataLink II
USB Flash Drive Installation Kit. This kit allows the DataLink II software and license disk to be
installed directly through the computers USB port. The DataLink II software does not require a
CD or Floppy Disk Drive for normal operation.
Screen Resolution
The DataLink II software requires a minimum screen resolution of 1024 x 768. We recommend
the use of the largest and highest resolution monitor that meets your installation and budget
requirements. If your PC is configured with dual monitor support, the DataLink II software has
special features to take advantage of the capabilities. A flat panel (1280 x 1024 resolution)
narrow outline monitor such as those manufactured by Dell and Fujitsu is optimum for high-end
applications.
