IQ3 Data Logger Dash Installation Manual
10
Technical Specifications
Total Sensor Channels - Defined Below 38
Vnet Data Channels 32
Internal Channels as defined below 7
IQ3 Internal Temperature/IQ3 Logger Voltage / Engine RPM / Accel G /
Lateral G / Vertical G / GPS
Accelerometer Specifications
Sample Rate 100HZ - 3 Axis
Accuracy 1% (excluding vibration affect)
Minimum / Maximum Values +5 / -5
GPS Information
GPS logging rate 4 Hz with 100HZ inertial assistance
Channels 16
Antenna High Gain / Active
Accuracy 2.5 Meters
Cold start / Hot start satellite sync time 34 seconds cold / less than 3.5 seconds hot
Memory
Maximum micro SD Card Size
512MB microSD Flash - Included
2GB Maximum
Data Writing Rate 17Kb / sec
Resolution (ADC)
Data Logger 10 bit
Processor Speed 20MHz
Sample (Logging) Rates of Data Channels
IQ3 Internal Channels 100 Hz Maximum, user adjustable to 1 Hz
Vnet Channels 100 Hz Maximum, user adjustable to 1 Hz
Power & Current
Input Voltage 10-16V
Current Draw 350mA - Without warning and shift LED’s active
Reverse Voltage Protection Yes
Operating Temperature 32 - 140F / 0-60C
Mounting Orientation Level left & right / Level top & bottom
Rear of dash facing direction of travel
Engine RPM Input 50% duty cycle, 5-18V square wave signal
Start Logging Channel (factory default) GPS Speed (25 MPH)
