IQ3 Data Logger Dash Installation Manual
30
DataLink II Help Files
The DataLink II software includes a complete selection of help files, which can be accessed as
shown below:
Main Menu or any open Dialog Box: To get help for any of the menu items simply highlight the
menu item by placing the mouse cursor over the menu item. Next press the F1 key to display
the help.
Icon Tool Bar: Select the ? button located at the bottom of the icon toolbar. The mouse
cursor will change to a? Position the mouse cursor over toolbar icon for which help is desired
and click the left mouse cursor. Help will be displayed
DataLink Program Screens: Select the ? button located at the bottom of the icon
toolbar. The mouse cursor will change to a? Position the mouse cursor over the section of the
DataLink II screen for which help is desired and click the mouse button. Help will be displayed.
Runlog Pages: To get help on a run log page look for the blue icon with a question mark.
Simply click on the button to display the help for the run log page.
Help from Main Menu: Click on the Help main menu selection and select the Help Topics menu
selection. The Help Topics: DataLink II Applications Help will be displayed. Follow the
instructions included with the help box to navigate thru the online help
Demo Run Data for Various Motorsports
During the software installation, a series of demo runs and an IQ3 demo manual were
automatically installed for the following types of motorsports:
1. IQ3 DemoRC
2. Boat Demo
3. Puller Demo
The IQ3 demo manual can be found by clicking Start->Programs->Racepak->Docs. Adobe
Acrobat Reader is required to view this file. We strongly recommend reviewing the data before
initial use of the IQ3. It is much easier to learn how to graph and review data in the comfort of
your home as opposed to attempting to learn “on the fly” during a hot day at the race track.
