Transmitter t4pls, Nomenclature – Futaba 4PLS 2.4GHz FHSS User Manual
Page 15
15
B
e
for
e
Using
7KHVZLWFKHVGLDODQGWULPPHUVLQWKH¿JXUHDUHVKRZQLQWKHLQLWLDOVHWWLQJSRVLWLRQ
Antenna
Digital Dial 1 (DL1)
(default CH4)
Mechanical ATL
adjusting screw
Throttle trigger
Power&Display switch
Digital Trim 2 (DT2)
(default throttle trim)
Digital Trim 4 (DT4)
(default ATL)
Digital Trim 3 (DT3)
(default dual rate)
Grip Handle
Digital Trim1 (DT1)
(default steering trim)
Steering wheel
Push switch (SW1)
Slide switch (SW2)
(default CH3)
LCD screen
Edit buttons
LED
Nomenclature
Transmitter T4PLS
Wheel tension
adjusting screw
Trigger tension
adjusting screw
Battery cover
Trigger slide
adjusting screw
