Fu n c tio n – Futaba 4PLS 2.4GHz FHSS User Manual

Page 111

Alarm ON/OFF
ON, OFF
- Select with the (+) or (-) but-

tons.

Voltage alarm
0.0V~90.0V
Initial value: 5V
Adjust button
- Adjust with the (+) and (-) but-

tons.

- Return to the initial value “0” by

pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.

Sensor type
SBS-01T, Temp 125
Select button
- Select with the (+) or (-) but-

tons.

Display type
°C, °F
- Select with the (+) or (-) but-

tons.

Alarm ON/OFF
ON, OFF
- Select with the (+) or (-) but-

tons.

Temperature alarm
-20~200°C/ -4~392°F
Initial value: 200°C/ 212°F
Adjust button
- Adjust with the (+) and (-) but-

tons.

- Return to the initial value “0” by

pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.

111

Fu
n

tio

Telemetry "TELEMETRY"

Setting external power supply voltage alarm

Display page 1 by (JOG) button left or right

operation.

Select "ALRM" of the "EXT VOLT" setting

items by (JOG) button up or down operation,

and set alarm ON/OFF with the (+) button or (-)

button.

"OFF" : Alarm OFF
"ON” : Alarm ON by a voltage drop below the speciﬁed voltage

Select "VOLT" of the "*EXT VOLT" setting items by (JOG)

button up or down operation, and set the voltage at which the

alarm begins to sound with the (+) button or (-) button. The

number of digits can be shifted by (JOG) button left or right

operation.

When ending, move the cursor to [RT] by the (JOG) button,

and return to the HOME screen by pressing the (JOG) but-

ton twice.

Setting the temperature alarm

Display page 2 by (JOG) button left or right operation.

Select "UNIT" of the "*TEMP" setting items by (JOG) button

up or down operation, and select Celsius or Fahrenheit tem-

perature display with the (+) button or (-) button.

"°C" : Celsius display
"°F" :

Fahrenheit

Select "ALRM" of the "*TEMP" setting items

by (JOG) button up or down operation, and

set alarm ON/OFF with the (+) button or (-)

button.

"OFF" : Alarm OFF
"ON"

: Alarm ON at the speciﬁed temperature

Select "TEMP" of the "*TEMP" setting items by (JOG) but-

ton up or down operation, and set the temperature at which

the alarm begins to sound with the (+) button or (-) button.

Select "TYPE" of the "*TEMP" setting items by (JOG) button

up or down operation, and set the type of sensor with the (+)

button or (-) button

"SBS-01T" : Option sensor
"Temp 125" : Option sensor for Europ

When ending, move the cursor to [RT] by the (JOG) button,

and return to the HOME screen by pressing the (JOG) but-

ton twice.
