FAD-40 Technical Manual, Rev. 1.06 December 2012 Page 43 of 52
See chapter 4.4.2
Digital I/O Connection
See chapter 4.2.3
Power Supply Connection
See chapter 4.2.1
8.3. Interfacing
FAD-40PN instruments have two interface connectors on the front of the instrument: ProfiNet and RS-232C.
The table below describes the data formats for interfacing the peripherals and their application.
Data Format Description Application Hardware
ProfiNet ProfiNet interfacing.
Refer to chapter 5.12 Interfacing with PLC. ProfiNet
Table 8.3
– Data output interfacing
Attention: Please disable the interface you will not use to increase the performance of the instrument.
8.4. Setup and Calibration
FAD-40PN instruments are set up and calibrated by xFace. The A/D Converter settings are very important for a
good weighing performance. Please refer to chapter 5.3.
8.5. ProfiNet Setup
The ProfiNet setup is done by xFace software as described in this chapter. Select the Gateway tab after
connecting xFace to the instrument. You will see the ProfiNet parameters in this tab.
ProfiNet Setup
There are 7 setup parameters for ProfiNet network.
DHCP Dynamic Host Configuration Protocol automates network parameters if it is enabled.
Default is „Disable‟.
IP Address If DHCP is disabled, define IP address manu ally. Default is „192.168.16.250‟
Subnet Mask If DHCP is disabled, define subnet mask manually. Default is „255.255.255.0‟.
Default Gateway If DHCP is disabled, define default gateway manually. Default is „192.168.16.254‟.
Primary DNS If DHCP is disable d, define primary DNS manually. Default is „208.67.222.222‟..
Secondary DNS If DHCP is disabled, define secondary DNS manually. Default is „208.67.220.220‟.
Host Name Enter a unique host name to the instrument. Default is „ ‟
ProfiNet Data Structure
Please refer to chapter 5.12
