FAD-40 Technical Manual, Rev. 1.06 December 2012 Page 23 of 52
Q Load setpoints
Command: [ADR][Q][SP NUMBER][SP TYPE][SIGN][SP VALUE]
Response: [ADR][Q][A]
Example:
Command: 01Q01L+000123.4
Response: 01QA (123.4 loaded to SP1_L)
01QN (could not load)
01QU (Mismatch of decimal point of SP VALUE)
Comments: SP No is 2 byte ASCII char. Use 01 for SP1, 02 for SP2 and 03 for SP3.
SP Type is 1 byte ASCII char. Use “L” for SPx_L and use “H” for SPx_H.
SP VALUE data is 8-byte ASCII char with dot and non-significant zeros on the left.
R Read setpoints
Command: [ADR][R][SP NUMBER][SP TYPE]
Response: [ADR][R][A][SIGN][SP VALUE]
Example:
Command: 01R01L
Response: 01RA+000123.4 (SP1_L is 123.4)
01RN (could not read)
Comments: SP No is 2 byte ASCII char. Use 01 for SP1, 02 for SP2 and 03 for SP3.
SP Type is 1 byte ASCII char. Use “L” for SPx_L and use “H” for SPx_H.
SP VALUE data is 8-byte ASCII char with dot and non-significant zeros on the left.
S Read Status
Command: [ADR][S]
Response: [ADR][S][STATUS-1][STATUS-2][STATUS-3]
Example:
Command: 01S
Response: 01SSGI (Stable, Gross, In Range)
01SDGL (Unstable, Gross, Low voltage error)
Comments: The response includes 3 status information.
STATUS-1 can be Stable or Unstable.
STATUS-2 can be Gross or Net.
STATUS-
3 can be „in range‟, „out of range‟, „low voltage‟ or „high voltage‟.
T Tare
Command: [ADR][T]
Response: [ADR][T][A] (Taring is done successfully and scale is in net)
[ADR][T][N] (Taring could not be executed)
[ADR][T][X] (Taring is disabled or instrument is in count mode)
Comments: The tare value will be overwritten by the new tare weight value. The status must be stable
within 2 seconds delay time. If so, Ack will be sent. Otherwise Nack will be sent.
U Read digital inputs
Command: [ADR][U]
Response: [ADR][U][A][INPUTS]
Example:
Command: 01U
Response: 01UA6 (Input 2 and input 3 are active)
01UN (could not read inputs)
Comments: .
Inputs IN-3 IN-2 IN-1
Bitwise 1 1 0
ASCII 6
