FAD-40 Technical Manual, Rev. 1.06 December 2012 Page 26 of 52
Address R/W Word Command Definition
40015 R/W 1
mV operation
in Count Mode
0 5 mV
1 10 mV
2 15 mV
3 18 mV
40016 R/W 1 Digital filters
0 Fast
1
2
3
4
5 Medium
6
7 Default
8
9 Slow
40017 1 Not used
40018 R/W 1
Status of
Digital I/O
D0 Input of I/O3
D1 Input of I/O2
D2
D3
D4
D5
D6
D7
D8 Output of I/O1
D9 Output of I/O2
D10 Output of I/O3
40019 R/W 1
Setup for I/O1
and I/O2
D0…D6
0000000 Disable
I/O1 output
function
0000001 Standard setpoint
0000010 Setpoint without hyster.
0000011 Window
0000100 Host output
D7
0 Active Low I/O1
polarity
1 Active High
D8…D14
0000000 Disable
I/O2 output
function
0000001 Standard setpoint
0000010 Setpoint without hyster.
0000011 Window
0000100 Host output
0000101 Zeroing
I/O2 input
functions 0000110 Taring
0000111 Clearing tare
0001000 Host input
D15
0 Active Low I/O2
polarity
1 Active High
40020 R/W 1 Setup for I/O3
D 0…D6
0000000 Disable
I/O3 output
function
0000001 Standard setpoint
0000010 Setpoint without hyster.
0000011 Window
0000100 Host output
0000101 Zeroing
I/O3 input
function 0000110 Taring
0000111 Clearing tare
0001000 Host input
D7
0 Active Low I/O3
polarity
1 Active High
