MIO 501 1.8V Peripherals
Pin ENET 0 USB 0 SDIO 0 UART 1 GPIO
16 TXCK
17 TXD0
18 TXD1
19 TXD2
20 TXD3
21 TXCTL
22 RXCK
23 RXD0
24 RXD1
25 RXD2
26 RXD3
27 RXCTL
28 DATA4
29 DIR
30 STP
31 NXT
32 DATA0
33 DATA1
34 DATA2
35 DATA3
36 CLK
37 DATA5
38 DATA6
39 DATA7
40 CCLK
41 CMD
42 D0
43 D1
44 D2
45 D3
46 RESETN
47 CD
48 RXD
49 TXD
50 BTN4
51 BTN5
52 MDC
53 MDIO
Table 3. MIO Pinout.
