4-4. CW OPERATION
AlP switch
When switched on, it
reduces interference from
strong signals.
FULL/SEMI switch
During CW operation, selects
either Full Break-in (FULL) or
Semi Break-in (SEMI).
VOX/MAN switch
Used to select Break-in
operation.
PLAY, REC keys
Records and plays CW
messages for transmission.
THRU/AUTO switch
THRU; Antenna tuner is off.
AUTO: Antenna tuner is on.
AGC switch
Set to MID
normally.
KEY SPEED control
This control the speed of the
electronic keyer.
PITCH key
Select the CW receive tone
(RECEIVING)
pT| Turn on the DC power supply and then turn the transceiver’s power switch ON.
|~2] A frequency is shown in the display.
Press the UP/DOWN switches to select the desired frequency band.
When the 1 MHz step position is selected, the MHz indicator will light.
[
4
] Select CW with the MODE key.
[~^ Turn the AF gain control clockwise until a signal or noise is heard.
Rotate the TUNING knob and select an open channel.
