SHEET 4001 WING RIBS 5/64 x 2-7/8” 2 REQ’D.
SHEET 4002 WING RIBS 5/64 x 2-7/8” 2 REQ’D.
DIE-CUT WOOD SHEETS
SHEET 4006 3/16x 2-7/8 x 9-1/2” 1 REQ’D.
SHEET 4008 1/16x 2-5/8 x 13-1/2” 1 REQ’D.
SHEET 4011 1/16x 2-5/8 x 13-1/2” 1 REQ’D.
SHEET 4010 1/16x 2-7/8 x 18” 1 REQ’D.
BATTERY HATCH FORMER C DOUBLER
HATCH DOUBLER SHEET 4009 1/8x 2-3/8 x 17” WING CENTER JOINERS 1 REQ’D.
SHEET 4005 1/16x 2-7/8 x 24” 1 REQ’D.
SHEET 4007 1/16x 2-7/8 x 24” 1 REQ’D.
SHEET 4012 1/16x 3 x 24” 2 REQ’D.
SHEET 4013 1/16x 3 x 24” 2 REQ’D.
SHEET 4014 1/8 x 2-1/4 x13” 2 REQ’D.
BEVELING MOTOR
TOOL WING GAUGE SWITCH
MOUNT
SHEET 4004 5/64 x 2-7/8 x 18” FUSELAGE SIDE DOUBLER 2 REQ’D.
7
STAB TIPS WING/TAIL GUSSETS STAB CENTER PLATFORM
DORSAL
FIN
STAB L.E.
JOINER
FIN
BOTTOM
FUSE REAR TOP
FORMER D
STAB PLATFORM
FUSE REAR BOTTOM
OUTBOARD PANEL L.E. SHEETING
MID CENTER SHEETING
INBOARD PANEL L.E. SHEETING
JOINER CLAMPS SERVO
MOUNTING
RAIL
FORMER B FORMER C
REAR MOTOR FORMER POLYHEDRAL
MOUNT A JOINERS
FUSE REAR DOUBLER
FUSE WING PLATFORM
FUSE BOTTOM
FRONT
HATCH
TONGUE
FORMER A
DOUBLER
SHEET 4003B FUSELAGE REAR SHEET 4003A FUSELAGE FRONT
