C-MORE CONTROL PANEL OPERATION
Table 3-1. Menu Item Descriptions - Continued
MENU LEVEL & OPTION DESCRIPTION
SETUP MENU
Password
Level 1
Level 2
Allows Level 1 or 2 password to be entered.
Entering the Level 1 Password (159) allows options in
the Setup, Configuration and Tuning Menus to be
modified.
Entering the Level 2 Password (6817) allows options
in the Calibration and Diagnostics Menus to be
changed/activated, in addition to all Level 1 Menu
options.
Language English is the ONLY language available
Time Displays time from 12:00am to 11:59pm.
Date Displays dates from 01/01/00 to 12/31/99
Unit of Temp Permits selection of temperature displays in degrees
Fahrenheit (°F) or degrees Celsius (°C). Default is
°F.
Comm Address For RS485 MODBUS communications (0 to 127).
Default address is 0.
Baud Rate Allows the RS232 communication Baud Rate to be
set (2400 to 19.2K). Default is 9600.
Software Version Identifies the current software version of the control
box (Ver 0.0 to Ver 9.9).
CONFIGURATION MENU
Internal Setpoint Allows internal setpoint to be set (40°F to 240°F).
Default is 130°F.
Unit Type Allows selection of Boiler or Water Heater. Default is
Boiler.
Unit Size Sets unit size from 0.5 to 3.0 MBTUs. Default is 1.0
MBTU.
Boiler Mode
(If Unit Type = Boiler) Allows selection of: Constant Setpoint, Remote
Setpoint, Direct Drive, Combination, or Outdoor Reset
Mode. Default is Constant Setpoint Mode.
Heater Mode
(If Unit Type = Water Heater) Allows selection of Constant Setpoint or Remote
Setpoint Mode. Default is Constant Setpoint Mode.
Remote Signal
(If Mode = Remote Setpoint,
Direct Drive or Combination) Used to set the type of external signal which will be
used when operating in the Remote Setpoint, Direct
Drive or Combination Mode. Default is 4 to 20 mA /
1 to 5V.
Bldg Ref Temp
(If Boiler Mode = Outdoor
Reset) Allows the building reference temperature to be set
when operating a Boiler in the Outdoor Reset Mode.
Default is 70°F
14
