C-MORE CONTROL PANEL OPERATION
2.7 CALIBRATION MENU
The Calibration Menu is used by Factory
Trained Service personnel to adjust or reset the
parameters listed in Table 2-5.
Table 2-5. Calibration Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Stepper Fbk
(Not adjustable via
RS232 serial
communication) Cal 0%
Cal 100%
Verify 50%
Cal 0%
PWM In Adj -5.0% 5.0% 0.0%
Analog In Adj -5.0% 5.0% 0.0%
Flow In Adj -5.0% 5.0% 0.0%
CO In Adj -5.0% 5.0% 0.0%
O2 In Adj -5.0% 5.0% 0.0%
mA Out Adj -1.0 mA 1.0 mA 0.0 mA
A/F Sensitivity 1% 5% 2%
Power Reset Automatic
Manual
Automatic
Water Temp Reset Automatic
Manual
Automatic
Gas Press Reset Automatic
Manual
Manual
Min Off Time 0 Min 15 Min 1 Min (Boiler)
0 Min (Water Heater)
Heatr Tuning Dsp
(If Unit Type = Water
Heater) Enabled or Disabled Disabled
Heatr Bkpt Dsp
(If Unit Type = Water
Heater) Enabled or Disabled Disabled
Stop Level 0% Start Level 16
Start Level Stop Level 40% 20
2.8 DIAGNOSTICS MENU
The Diagnostics Menu shown in Table 2-6 is
used by Factory-Trained Service personnel to
troubleshoot the unit. This menu category
contains a number of Built In Test (BIT) test
routines to be used to check the operational
status of the Control Panel displays and keypad
keys. It also allows the operator to activate
relays, view switch status and increment the
stepper motor contained in the Air/Fuel Valve.
NOTE
With the exception of the Sensor Log Interval
(Int) setting, none of the following Diagnostic
Menu items can be initiated via a remote serial
communications link.
