C-MORE CONTROL PANEL OPERATION
Table 2-3. Configuration Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Internal Setpt Lo Temp Limit Hi Temp Limit 130°F
Unit Type Boiler
Water Heater
Boiler
Unit Size 0.5 MBTU
1.0 MBTU
1.5 MBTU
2.0 MBTU
2.5 MBTU
3.0 MBTU 1.0 MBTU
Boiler Mode
(If Unit Type = Boiler) Constant Setpoint
Remote Setpoint
Direct Drive
Combination
Outdoor Reset
Constant
Setpoint
Heater Mode
(If Unit Type = Water Heater) Constant Setpoint
Remote Setpoint
Constant
Setpoint
Remote Signal
(If Mode = Remote Setpoint,
Direct Drive or Combination) 4 – 20 mA/1 – 5V
0 -20 mA/0 – 5V
PWM Input (BMS)
Network
4 to 20 mA/
1-5V
Bldg Ref Temp
(If Boiler Mode = Outdoor
Reset) 40°F 230°F 70°F
Reset Ratio
(If Boiler Mode = Outdoor
Reset) 0.1 9.9 1.2
Outdoor Sensor Enabled or Disabled Disabled
System Start Tmp
(If Outdoor Sensor =
Enabled) 30°F 100°F 60°F
Setpt Lo Limit 40°F Setpt Hi Limit 60°F
Setpt Hi Limit Setpt Lo Limit 240°F 200°F
Temp Hi Limit 40°F 240°F 210°F
Max Fire Rate 40% 100% 100%
Pump Delay Timer
(If Unit Type = Boiler) 0 min 30 min 0 min
Aux Start On Dly 0 sec 120 sec 0 sec
Failsafe Mode Shutdown or Constant Setpt Shutdown
mA Output Setpoint
Outlet Temp
Fire Rate Out
Off
Off
Low Fire Timer 2 sec 120 sec 2 sec
Setpt Limiting Enabled or Disabled Disabled
Setpt Limit Band 0°F 10°F 5°F
