MODULEX EXT 321, 481, 641, 802, 962, 1123 BOILERS
Installation, Operation & Maintenance Manual
There are six top level menus and five sub-menus as listed below.
Menus (Top Level): 5.3.1
• GENERAL
Value selection summary. Service => for service engineers. Date/Time/Holiday => for
users.
• DISPLAY
System value display (e.g. sensor values and setpoints). No adjustments can be made.
Operating errors are therefore excluded in this area.
• USER
Summary of settings that can be made by the operator.
• TIME PROGRAMS
Summary of time programs for heating circuits, the hot water circuit and extra functions
where applicable
• EXPERT
Summary of values for which expert knowledge is required to make settings (installation
technician). Values in the expert level are protected by a code number.
• EXPERT FA (Only for FA via BUS)
Summary of values transmitted by the automatic firing device.
Sub-Menus: 5.3.2
• INSTALLATION
All display values and settings that relate to the unit or the entire system and cannot be
assigned to a consumer circuit.
• HOT WATER
All display values and settings that affect central hot water preparation and circulation.
• HEATING CIRCUIT I
All indicator and set values that relate to the consumer circuit 1 (also, for example, as
decentralized hot-water circuit).
• HEATING CIRCUIT II
All indicator and set values that relate to the consumer circuit 2 (also, for example, as
decentralized hot-water circuit).
• SOLAR/MF
All indicator and set values that relate to solar energy recovery and settings for the
multifunction relay.
