AERCO Modulex EXT 321 - 1123 User Manual
Page 55
MODULEX EXT 321, 481, 641, 802, 962, 1123 BOILERS
Installation, Operation & Maintenance Manual
Figure 3-28: 120VAC Power Wiring for Main Electrical Junction Box and Signal
Wiring for E8 Controller and Boiler Control Module (BCM)
WARNING!
120 VAC cables shall be separated from 24VAC and signal wires,
using the two plastic conduits supplied within the boiler casing
LEFT-HAND side panel.
AUX
AUX
OMM-0087_0E
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
Page 55 of 148
GF-143
Phone: 800-526-0288
12/01/14
