10

KV-E8R (8-point expansion output unit (relay output type))
Terminal layout drawing

Output circuit diagram

C2

5

7

V4

4

6

V3

C1

1

3

V2

0

2

V1

7

6

5

4

C2

V4

V3

V1

V2

2

0

3

1

C1

0 to 3
4 to 7

C1
C2

Internal circuit

• C1 and C2 are each

independent.

• V1 to V2 and V3 to V4 are

short-circuited inside (so
they can be used as relay
terminal plates).

Internal circuit

KV-E16R (16-point expansion output unit (relay output type))
Terminal layout drawing

Output circuit diagram

C3

9

11

C4

13

15

8

10

12

14

C1

1

3

C2

5

7

0

2

4

6

11

10

9

8

C3

2

0

3

1

C1

15

14

13

12

C4

6

4

7

5

C2

Internal circuit

0 to 3
4 to 7
8 to 11
12 to15

C1
C2
C3
C4

• C1 and C4 are each independent.

Internal circuit
