3-3 Explicit Messaging
3-29
3
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-S
s
er
ie
s
- DeviceNet Compatible Network Unit DL-DN1 User’s Manual (FD-S) -
Nx10+4
64
Group-4 entry count
R
-
29
65
System reserved
66
Detection mode
R/W
-
0
0: F-1
1: F-2
2: F-3
3: A-1
4: A-2
67
System reserved
68
Response time
R/W
-
3
0: 0.05 s
1: 0.1 s
2: 0.5 s
3: 1.0 s
4: 2.5 s
5: 5.0 s
6: 10.0 s
7: 30.0 s
8: 60.0 s
69
Average display
R/W
-
01.0 00.0 to 10.0 (in steps of 0.5)
6A
Time-out time for
output 2
R/W
-
10
1 to 99
6B
Integration direction
R/W
-
0
0: Increment
1: Decrement
6C
Integrated flow quantity
unit (for version A)
R/W
FD-SS02
4
1: 0.01 / 2: 0.1 / 3:1 / 4: 10 / 5: 100 / 6: 1000
FD-SF1(S)
4
2: 0.1 / 3: 1 / 4: 10 / 5: 100 / 6: 1000 / 7: 10000
FD-SF1(F)
4
1: 0.01 / 2:0.1 / 3:1 / 4: 10 / 5: 100 / 6: 1000
FD-SS2(S)
4
3: 1 / 4: 10 / 5: 100 / 6: 1000 / 7: 10000
FD-SS2(F)
4
2: 0.1 / 3: 1 / 4: 10 / 5: 100 / 6: 1000
FD-SF8(S)
4
0: 0.001 / 1: 0.01 / 2: 0.1 / 3: 1 /4: 10 / 5: 100
FD-SF8(F)
4
2: 0.1 / 3: 1 / 4: 10 / 5: 100 / 6: 1000 / 7: 10000
FD-SS20(S)
4
1: 0.01 / 2: 0.1 / 3: 1 / 4: 10 / 5: 100
FD-SS20(F)
4
3: 1 / 4: 10 / 5: 100 / 6: 1000 / 7: 10000
6D
Zero cut level
*9
R/W
FD-SS02
010.0 000.0 to 400.0
FD-SF1(S)
0050 0000 to 2000
FD-SF1(F)
010.0 000.0 to 400.0
FD-SS2(S)
0100 0000 to 4000
FD-SS2(F)
010
0000 to 400
FD-SF8(S)
00.40 00.00 to 16.00
FD-SF8(F)
0100 0000 to 4000
FD-SS20(S) 01.00 00.0 to 40.0
FD-SS20(F)
0100 0000 to 4000
6E
Low density zero cut
function
*10
R/W
-
0
0: ON
1: OFF
6F
Low density zero cut
level
*10
R/W
-
0.50 0.01-2.00
70
System reserved
71
N.O/N.C
R/W
-
0
Bit 0: Output 1 (1: N.C.)
Bit 1: Output 2 (1: N.C.)
Bit 2: Output 3 (1: N.C.)
72
Display mode
R/W
-
0
0: Std
1: rESo
InstID
(DEC)
AttrID
(HEX)
Name
Description Attribute
Sensor
head
Default
value
Parameter range
