3-3 Explicit Messaging
3-28
- DeviceNet Compatible Network Unit DL-DN1 User’s Manual (FD-S) -
3
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-S
s
er
ie
s
Nx10+2
6B
Instantaneous flow rate
setting 3 (P3)
*3
R/W
FD-SS02
130.0 000.0 to 400.0
FD-SF1(S)
0700 0000 to 2000
FD-SF1(F)
130.0 000.0 to 400.0
FD-SS2(S)
1300 0000 to 4000
FD-SS2(F)
130.0 000.0 to 400.0
FD-SF8(S)
05.00 00.00 to 16.00
FD-SF8(F)
1300 0000 to 4000
FD-SS20(S) 13.00 00.00 to 40.00
FD-SS20(F) 1300 0000 to 4000
6C
Instantaneous flow rate
setting 4 (P4)
*3
R/W
FD-SS02
200.0 000.0 to 400.0
FD-SF1(S)
1000 0000 to 2000
FD-SF1(F)
200.0 000.0 to 400.0
FD-SS2(S)
2000 0000 to 4000
FD-SS2(F)
200.0 000.0 to 400.0
FD-SF8(S)
8.00 00.00 to 16.00
FD-SF8(F)
2000 0000 to 4000
FD-SS20(S) 20.00 00.00 to 40.00
FD-SS20(F) 2000 0000 to 4000
6D
System reserved
6E
Specified density for
voLS
6F to
83
System reserved
Nx10+3
64
Group-3 entry count
R
-
5
65
Key locked
R/W
-
0
0: Deactivate key lock
1: Key lock
66
System reserved
67
Analog output selection
*8
R/W
-
0
0: Standard
1: Free range analog
68
Free range analog
upper limit
*8
R/W
FD-SS02
000
000 to 400
FD-SF1(S)
000
0000 to 2000
FD-SF1(F)
000
000 to 400
FD-SS2(S)
0000 0000 to 4000
FD-SS2(F)
000
000 to 400
FD-SF8(S)
00.0 00.0 to 16.0
FD-SF8(F)
0000 0000 to 4000
FD-SS20(S)
00.0 00.0 to 40.0
FD-SS20(F) 0000 0000 to 4000
69
Free range analog
lower limit
*8
R/W
FD-SS02
200.0 000 to 400
FD-SF1(S)
1000 0000 to 2000
FD-SF1(F)
200
000 to 400
FD-SS2(S)
2000 0000 to 4000
FD-SS2(F)
200
000 to 400
FD-SF8(S)
0.40 00.0 to 16.0
FD-SF8(F)
0100 0000 to 4000
FD-SS20(S)
20.0 00.0 to 40.0
FD-SS20(F) 2000 0000 to 4000
6A to
83
System reserved
InstID
(DEC)
AttrID
(HEX)
Name
Description Attribute
Sensor
head
Default
value
Parameter range
