3-2 I/O Communication
3-6 - DeviceNet Compatible Network Unit DL-DN1 User’s Manual (FD-S) -
3
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-S
s
er
ie
s
"3-output + current value" mode
5-output mode
"5-output + current value" mode
3-output + monitor
No extended mode Yes - -
3-input - Yes Yes
Setting value rewrite - - Yes
Area IN OUT IN OUT IN OUT
Number of sensor amplifi ers
1 14
0
20
6
28
24
2 18 24 32
3 22 28 36
4 26 32 40
(bytes)
5-output
No extended mode Yes - -
5-input - Yes Yes
Setting value rewrite - - Yes
Area IN OUT IN OUT IN OUT
Number of sensor amplifi ers 1-4 12 0 22 10 34 40
(bytes)
5-output + current value
No extended mode Yes - -
5-input - Yes Yes
Setting value rewrite - - Yes
Area IN OUT IN OUT IN OUT
Number of sensor amplifi ers
1 18
0
28
10
40
40
2 22 32 44
3 26 36 48
4 30 40 52
(bytes)
