3-3 Explicit Messaging
3-27
3
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-S
s
er
ie
s
- DeviceNet Compatible Network Unit DL-DN1 User’s Manual (FD-S) -
Nx10+1
75
Integrated flow quantity
(except for version A)
R
FD-SS02 - -21474836.4 to +21474836.4
FD-SF1(S) -214748364 to +214748364
FD-SF1(F) -21474836.4 to +21474836.4
FD-SS2(S) -214748364 to +214748364
FD-SS2(F) -21474836.4 to +21474836.4
FD-SF8(S) -2147483.64 to +2147483.64
FD-SF8(F) -21474836.4 to +21474836.4
FD-SS20(S) -2147483.64 to +2147483.64
FD-SS20(F) -21474836.4 to +21474836.4
76 to
77
System reserved
78 External Input Status R - -
0: OFF
1: ON
79 System reserved
7A
Shift system
processing result
R - 0
0: Successfully completed.
1: Abnormally terminated
7B to
83
System reserved
Nx10+2
64 Group-2 entry count R - 10
65
Instantaneous flow rate
setting 1 (P1)
*3 R/W
FD-SS02 030.0 000.0 to 400.0
FD-SF1(S) 0300 0000 to 2000
FD-SF1(F) 030.0 000.0 to 400.0
FD-SS2(S) 0300 0000 to 4000
FD-SS2(F) 030.0 000.0 to 400.0
FD-SF8(S) 02.00 00.00 to 16.00
FD-SF8(F) 0300 0000 to 4000
FD-SS20(S) 03.00 00.00 to 40.00
FD-SS20(F) 0300 0000 to 4000
66
Instantaneous flow rate
setting 2 (P2)
*3 R/W
FD-SS02 100.0 000.0 to 400.0
FD-SF1(S) 0500 0000 to 2000
FD-SF1(F) 100.0 000.0 to 400.0
FD-SS2(S) 1000 0000 to 4000
FD-SS2(F) 100.0 000.0 to 400.0
FD-SF8(S) 04.00 00.00 to 16.00
FD-SF8(F) 1000 0000 to 4000
FD-SS20(S) 10.00 00.00 to 40.00
FD-SS20(F) 1000 0000 to 4000
67
Temperature upper limit
setting
*6 R/W
SUS type 80.0
000.1 to 100.0
PFA type 60.0
68
Temperature lower limit
setting
*7 R/W - 10.0 000.0 to 099.9
69
Integrated flow quantity
setting 1
R/W - 0150 0000 to 9999
6A
Integrated flow quantity
setting 2
R/W - 9999 0000 to 9999
InstID
(DEC) AttrID
(HEX)
Name Description Attribute
Sensor
head
Default
value
Parameter range
