20
SPECIFICATIONS
Type High resolution Standard Long range
Model Sensor head LB-041 LB-081 LB-301
Controller LB-1001W LB-1101W LB-1201W
Reference distance 40 mm 80 mm 300 mm
Measuring range ±5 mm ±15 mm ±100 mm
Light source Visible red semiconductor laser Invisible infrared semiconductor laser
Output 3.0 mW (FDA), 2.0 mW (IEC) 3.0 mW (FDA), 2.5 mW (IEC) 20 mW (FDA), 15 mW (IEC)
Pulse duration 35 µs
Wavelength 670 nm 785 nm
Laser FDA (CDRH) 21CFR Part 1040.10 Class IIIa Class IIIb
Class IEC/EN 60825-1 Class 2M Class 3R Class 3B
Spot diameter (with white paper) 1 x 2 mm (at reference distance) 1.2 x 2.5 mm (at reference distance)
Linearity 0.25% of F.S. 0.4% of F.S.
Resolution (at LO mode) 2 µm 8 µm 50 µm
Output Analog voltage ±5 V (1 mm/V) ±5 V (3 mm/V) ±5 V (20 mm/V)
Impedance 100 Ω
Analog current 4 to 20 mA (350 Ω max.)
Alarm NPN open-collector: 100 mA (40 V) max. (N.C.) Residual voltage: 1 V max.
Adjustment range Zero-point ±0.35 V max. 1.
Span ±4% max.
Response frequency (-3 dB) 915 Hz (HIGH), 36 Hz (MID), 9 Hz (LO)
Sensitivity WHITE, BLACK and AUTO (switch selectable)
Other functions AUTO ZERO, Response speed selectable, Fuzzy logic control, Interference suppression
Temperature Sensor head 0.02% of F.S./°C
fluctuation Controller 0.02% of F.S./°C
Ambient light 2. 2,500 lux max. 4,000 lux max.
Ambient Sensor head 0 to +45°C (32 to 113°F)
temperature Controller 0 to +50°C (32 to 122°F), No condensation
Relative humidity 35 to 85%, No condensation
Power supply 24 VDC ±10%, Ripple (P-P): 10% max.
Current consumption (Max.) Approx. 320 mA Approx. 350 mA
Vibration resistance 10 to 55 Hz, 1.5 mm double amplitude in X, Y, and Z directions, 2 hours respectively
Material Sensor head Aluminum die-cast
Controller Polycarbonate
Weight Sensor head Approx. 170 g Approx. 250 g
Controller Approx. 500 g
1. Every measuring point within measuring range can be shifted to zero with the AUTO ZERO
function.
2. Incandescent/fluorescent lamps
The LB-1000 series controller and sensor head are calibrated as a pair. Therefore, to satisfy
specifications, combine units having the same serial number.
Option
Extension cable
The sensor head cable can be extended up to 40 m.
Model Cable length
LB-C2 2 m
LB-C3 3 m
LB-C8 8 m
