78
This test procedure requires that the initial analog option calibration procedure has been
completed.
To test the 0-10v output mode:
1. Enter the Setup Mode (see Setup Mode on page 15).
Chngs Poss!
P110.-- ~ F.S.= ~ 100.00
2. Attach the voltmeter + (red) lead to pin 3 (0-10VDC) and the - (black) lead to pin 2
(ISOLATED GND) of the Analog Output connector.
3. Key in 62002 [SELECT].
Test ~ 0-10v
Per P176
4. Press [SAMPLE/Enter] to set the output to 0%.
0-10v ~ 0P
0.00 VDC
5. Press [SAMPLE/Enter] to increase the output to 25%.
0-10v ~ 25P
2.50 VDC
6. Press [SAMPLE/Enter] to increase the output to 50%.
0-10v ~ 50P
5.00 VDC
7. Press [SAMPLE/Enter] to increase the output to 75%.
0-10v ~ 75P
7.50 VDC
8. Press [SAMPLE/Enter] to increase the output to 100%.
0-10v ~ 100P
10.00 VDC
To test the 0-20mA output mode:
Voltmeter readings are based on the use of a 500 ohm precision resistor. Caution! Do not exceed
500 ohms.
1. Enter the Setup Mode (see Setup Mode on page 15).
Chngs Poss!
P110.-- ~ F.S.= ~ 100.00
2. Attach the precision resistor to pin 5 and pin 6.
3. Attach the voltmeter + (red) lead to pin 6 (0-20 mA) of the analog output connector.
4. Attach the voltmeter - (black) lead to pin 5 (ISOLATED GND) of the Analog Output
connector.
5. Key in 62003 [SELECT].
Test ~ 0-20A
Per P176
6. Press [SAMPLE/Enter] to set the output to 0%.
0-20A ~ 0P
0.00 V
7. Press [SAMPLE/Enter] to increase the output to 25%.
0-20A ~ 25P
