30
Choice 7:
Choice 8:
Choice 9:
Choice 10:
Choice 11:
Choice 12:
Use choice 12 to send to a 450/455/550 remote display that is set to text mode and a
terminator.
Choice 13:
Choice 14 (Simulates NCI 3835):
Signed DATA
Data Block Name Description
A single control code, decimal value of 2.
A single control code, decimal value of 3.
A for positive data or a - for negative data.
8 characters right justified, space padded, including a decimal point and polarity sign.
Polarity is a ‘+’ or ‘–‘ to the immediate left of the most significant digit.
8 characters right justified, space padded, including a decimal point.
Two characters indicating pounds or kilograms.
Single word for gross weight, net weight or quantity.
An 'O' (overload/underload), 'M' (motion), or otherwise
See Setpoint Status below.
A single control code, decimal value of 13.
A single control code, decimal value of 10.
ASCII Space, decimal value of 32.
Setpoint Status
Transmitting the setpoint status will reflect the current state of all the setpoints, regardless of
which setpoint operation is configured. The status can be read as a single ASCII numeric
character (0-7), a Hex value (30h-37h) or a binary bit comparison. Status is preceded by a
and an "S". The preceding data stream format is for fixed transmissions of as
specified above. This is not associated with the custom transmission of parameter P96.
SP 1 SP 2 SP3 ASCII Hex Bit Comparison
Off Off Off 0 30h 0011 0000
On Off Off 1 31h 0011 0001
Off On Off 2 32h 0011 0010
On On Off 3 33h 0011 0011
Off Off On 4 34h 0011 0100
On Off On 5 35h 0011 0101
Off On On 6 36h 0011 0110
On On On 7 37h 0011 0111
