Seymour Midwest Great Rake II(PK90568) User Manual
Great rake ii / lake rake assembly instructions
1.
Insert the handle, Part “C”, into head, Part “A”, and fasten.
2.
Align holes in one brace, Part “B”, with holes in the other brace
and start fasteners.
3. Then align the remaining brace slots to the head and fasten.
Snug up braces clamping on to the handle, but DO NOT
OVER TIGHTEN.
GREAT RAKE II / LAKE RAKE
ASSEMBLY INSTRUCTIONS
P.O. Box 1674 Warsaw, Indiana 46581-1674
844-SEYMOUR 574-267-8508 FAX
www.seymourmidwest.com
PK90568
Short bolts
Long bolts
DO NOT OVER-
TIGHTEN
(Clamps should not touch.)
