PROBLEM SOLVING

Replacing the Drum Unit

Never expose the drum uiiit to ambient room light or sunlight while replacing it. The drum contains a photosensitive surface.

Exposing it to light may damage the drum.

1

Open the receiving cover.

2

Lift the drum unit by the four tabs as shown below.

Dnim Unit

Receiving Cover

Tab

3

Install a new drum unit (see page 11).

4

Close the receiving cover gently imtil it locks into position.

5

Reset the drum counter (see page 117).

m
