PROBLEM SOLVING

Paper Jam 002

CAUTION

• The fuser is hot; do not touch it.

• Avoid getting toner on your hands.

• Do not touch the green drum surface.

Open the receiving cover by pulling up the lock release lever and lifting it until it stops. If the paper is in the transfer area,

remove the developer unit and remove the jammed paper.

Fuser Area jammed Paper

Transfer Area

Check for paper in the fuser area. If the paper is in the fuser area, remove the drum unit and remove the jammed paper.

Jammed Paper

After removing the jammed paper, reinstall the developer/drum unit. Close the receiving cover imtil it locks into position.

109
