Chapter 4: Effect parameters
Ping-Pong Delay — PDL
The ping-pong delay effect delays the signal, then outputs the signal to the left and right outputs
alternately, so the delayed signal appears to bounce across the stereo image.
DLY Delay Time 0.1 ~ 450 msec
FB Feedback Level 0 - 1 0 0 %
The amount of effected signal that is fed
back into the effect.
DIR Direction
L L —> bounce from L to R.
R <— R bounce from R to L.
MIX Mixing Balance 0 - 100%
0 = dry signal.
50 = 50% ping-pong delay 50% dry signal.
100 = 100% ping-pong delay.
LVL Output Level - o°, -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPF:THRU,
32 Hz - 1.0 kHz
LPF: 1.0 k H z - 1 6 kHz,
THRU
Stereo Modulation Delay — SMD
The stereo modulation delay effect delays the left and right output signals using different delay
times, then modulates both delay times. It produces a rich stereo thickening effect, similar to
chorus hut with two independent delays and feedback parameter.
DLYL
Left Channel Delay
Time
0.1 - 450 msec
DLYR
Right Channel
Delay Time
0.1 - 450 msec
FB Feedback Level 0 - 1 0 0 %
The amount of effected signal that is fed
back into the effect.
SPD Modulation Speed 0.1 Hz - 20 Hz
DEP Modulation Depth 0 - 1 0 0 %
L/R L/R Balance L50 - L=R - R50
If the DLYL and DLYR parameters are set to
the same (or similar) delay times, this effect
may sound like a signal phasing problem. If
so, adjust the L/R parameter to correct it.
MIX Mixing Balance 0 - 100%
0 = dry signal.
50 = 50% stereo mod delay 50% dry signal.
100 = 100% stereo mod delay.
LVL Output Level - oo, -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPFiTHRU,
32 Hz - 1.0 kHz
LPF; 1.0 kHz - 16 kHz,
THRU
23
