Chapter 4: Effect parameters
Stereo Pitch 2 — PI 2
The stereo pitch 2 effect offers output pitch shifting like the Stereo Pitch 1 effect, with the addi­
tion of independent left and right output delays and feedback.
PCL
Left Channel Pitch
Coarse
- 1 2 - + 1 2 + 1 2 semitones.
PFL
Left Channel Pitch
Fine
-99 ~ +99 + 99 cents. (100 cents = 1 semitone)
DLYL
Left Channel Delay
Time
0.1 ~ 400 msec
PCR
Right Channel
Pitch Coarse
- 1 2 - + 1 2 ± 1 2 semitones.
PFR
Right Channel
Pitch Fine
-99 ~ +99 + 99 cents. (100 cents = 1 semitone)
DLYR
Right Channel
Delay Time
0.1 - 400 msec
VolL
Left Channel
Volume
0 - 1 0 0
VoIR
Right Channel
Volume
0 - 1 0 0
FB Feedback Level 0 - 1 0 0 %
The signal that is fed back will, obviously, be
pitch shifted again, and again.
KEY Base Key Off, Cl - C6 See page 34.
MIX Mixing Balance 0 - 1 0 0 %
0 = dry signal.
50 = 50% stereo pitch 50% dry signal.
100 = 100% stereo pitch.
LVL Output Level - oo, -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPFrTHRU,
32 Hz - 1.0 kHz
LPF: 1.0 kHz - 16 kHz,
THRU
