Chapter 4: Effect parameters
Stereo Pitch 1 — PII
The stereo pitch 1 effect is a pitch shifter that allows independent pitch shifting for the left and
right outputs. Signals can be pitch shifted by up to ± 12 semitones, with 99 cent fine control.
PCL
Left Channel Pitch
Coarse
-12 ~ +12 ±12 semitones.
PFL
Left Channel Pitch
Fine
-99 ~ +99 ± 99 cents. (100 cents = 1 semitone)
PCR
Right Channel
Pitch Coarse
-12 ~ +12 + 12 semitones.
PFR
Right Channel
Pitch Fine
-99 ~ +99 ± 99 cents. (100 cents = 1 semitone)
DLY Delay Time 0.1 ~ 58.0 msec
VolL
Left Channel
Volume
0 - 1 0 0
VOIR
Right Channel
Volume
0 - 100
KEY Base Key Off, Cl - C6 See page 34.
WID Sound Image Width 0 - 1 0
0=mono.
10=wide stereo.
MIX Mixing Balance 0 - 1 0 0 %
0 = dry signal.
50 = 50% stereo pitch 50% dry signal.
100 = 100% stereo pitch.
LVL Output Level - -30 dB - +6 dB Sets the output level of the effect.
Typ Filter Type HPF, LPF
Frq Cut Off Frequency
HPFTHRU,
32 Hz - 1.0 kHz
LPF; 1.0 kHz - 16 kHz,
THRU
21
