FI-521 Indicator Operation & Service Manual
────────────────────────────────────────────────────────
40
27 Meaning of Some Symbols and Troubleshooting
27.1 Meaning of Symbols:
27.1.1 0﹉﹉﹉﹉ ------ Zero is over the setting range
27.1.2 0﹍﹍﹍﹍ ------ Zero point is below the setting range
27.1.3 Ad﹉﹉﹉ ------ Signal to ADC is over max. range）
27.1.4 Ad﹍﹍﹍ ------ Signal to ADC is below min. range
27.1.5 ﹉﹉﹉﹉ ------ Force is over upper limitation, or display data is over limitation
27.1.6 ﹍﹍﹍﹍ ------ Force is below lower limitation
27.1.7 EEP.E1 ------ CONFIG or CAL parameters are not correctly set
27.1.8 EEP.E2 ------ USER parameter is not correctly set
27.1.9 Lo.bAt ------ Battery voltage is lower than setting.
27.1.10 CAP.- - - ---- Next displaying content is Capacity
27.1.11 CAP.ER ----- Setting Capacity is over display range
27.1.12 CAL.Px ----- Calibration on point(x)
27.1.13 CAL.OFF ----- Calibration Seal Switch is on OFF position
27.1.14 CAL.ON ----- Calibration Seal Switch is on ON position
27.1.15 CAL.Er ----- Calibration error, maybe input data or applied load is incorrect, unstable, un-linear
27.1.16 CAL.End ------- Calibration is end
27.1.17 OFF ------ Power OFF the indicator
