Front Panel Description
1
Colored insert:
4 colors
included: white (w/black logo),
white (w/ almond logo), almond
(w/black logo) and black (w/white
logo).
2
98 x 64 pixel LCD display.
3
Clear lens
covers and protects
the LCD display and helps sup-
port different color templates
which mount behind the lens.
4
LED indicators
. Indicate the
current “level” of the linked
parameter(s).
5
Encoder Knob with momen-
tary push switch
is the user
input to the SR 3.
1
2
3
4
5
