Rane SR 3 - Manual (Page 22)

Manual-22
Cable Type 2
4 twisted pair unshielded CAT 5, Belden #1583(A, B, E, ENH, R)
4 twisted pair shielded CAT 5, Belden #1624 (P, R)
4 twisted pair unsheilded CAT 5, Belden #1700 (A, R)
Max Distance
for Cable (feet)
Max Distance for
Cable (meters)
Number of
SR 3 Remotes
Vs = 15V
RPM 44
RPM 22
1000 305 1
1000 305 2
1000 305 3
1000 305 4
872 266 5
734 224 6
633 193 7
557 170 8
Vs = 12V
RPM 88
1000 305 1
1000 305 2
877 267 3
672 205 4
545 166 5
459 140 6
396 121 7
348 106 8
Vs = 8V 447 136 1
252 77 2
175 53 3
134 41 4
109 33 5
92 28 6
79 24 7
70 21 8
Note: This table is only for systems using just SR 3 remotes (all remotes on 485
bus are the same). For mix and match calculation of SR 2, SR 3 and SR 4 Remotes,
use the SRCABLELENGTH.XLS Microsoft Excel™ spreadsheet on the Drag Net CD-
ROM or at www.rane.com/sr3.html.
Requires
external
supply
