Stored Parameter List (SPL)
Below is a table of stored parameters followed by descriptions of each parameter.
Index Description
Value Range
Setting
Meaning
1
Back light Maximum Brightness
1 - 255
190
0.4 - 100 %
2
Back light Minimum Brightness
1 - 255
1
0.4 - 100 %
3
Back light Timer (.1 sec)
1 - 255
150
0.1 - 25.5 seconds, ignored if SPL 2 >= SPL 1.
4
Auto Page - Knob Push & Turn
0 - 1
1
disabled - enabled
5
Maximum Number of Pages
0 - 16
16
0 - 16 Pages, ignored if SPL 4 & 12 disabled.
6
Knob Push & Turn Page Roll
0 - 1
0
disabled - enabled, ignored if SPL 4 disabled.
7
Auto Level - Knob Turn
0 - 1
1
disabled - enabled
8
Auto Lock - Hardware
0 - 1
1
disabled - enabled
9
Baud Rate
0 - 4
2
0 = 9600, 1 = 19200, 2 = 38400, 3 = 57600, 4 = 115200
10
RW 485 Transmit Delay (ms)
2 - 200
10
2 - 200 milliseconds
11
Knob Push & Turn Update on Release 0 – 1
1
disabled - enabled, ignored if SPL 4 disabled.
12
Auto Page - Knob Bump
0 – 1
0
disabled - enabled
13
Knob Bump Update Timer (sec)
0 – 5
3
0 - 5 seconds, ignored if SPL 12 disabled. Knob Push & Turn updates take priority over time out.
14
Auto Title Page
0 – 1
0
disabled - enabled
15
Title Page Timer (sec)
1-25
5
1 - 25 seconds, ignored if SPL 14 disabled.
Parameter Descriptions
1. Back light maximum brightness ranges from 1 through 255 and controls the maxi-
mum brightness of the LCD light.
2. Back light minimum brightness ranges from 1 through 255 and controls the mini-
mum brightness of the LCD back light. If the minimum brightness is configured
to a value greater than the maximum brightness, the back light timer is defeated
and the brightness is set to the maximum value.
3. Back light timer configuration ranges from 1 through 255 which corresponds to a
time interval of 0.1 through 25.5 seconds. The back light is illuminated to maxi-
mum brightness when the device is powered up or when the encoder is activated.
The back light stays illuminated at the maximum brightness until the back light
time has expired, then the back light fades to the minimum brightness.
4. Auto Page - Knob Push & Turn configuration affects the result of turning the en-
coder while it is pushed in. If this parameter is enabled (a value of 1), the next page
bitmap is displayed based on the configuration of parameters 5 and 6. The page
index is updated based on the configuration of parameter 11. The configuration of
this parameter also affects the commands PS, IS, ISR, and IF. See SR 3 Com-
mand Set
section for details of how these commands are affected.
5. Maximum Number of Pages configures the number of pages that can be accessed
by the encoder (Knob Push & Turn and/or Knob Bump). This parameter is ig-
