Stored Parameter List (SPL)
Below is a table of stored parameters followed by descriptions of each parameter.
Index Description Value Range Setting Meaning
1 Back light Maximum Brightness 1 - 255 190 0.4 - 100 %
2 Back light Minimum Brightness 1 - 255 1 0.4 - 100 %
3 Back light Timer (.1 sec) 1 - 255 150 0.1 - 25.5 seconds, ignored if SPL 2 >= SPL 1.
4 Auto Page - Knob Push & Turn 0 - 1 1 disabled - enabled
5 Maximum Number of Pages 0 - 16 16 0 - 16 Pages, ignored if SPL 4 & 12 disabled.
6 Knob Push & Turn Page Roll 0 - 1 0 disabled - enabled, ignored if SPL 4 disabled.
7 Auto Level - Knob Turn 0 - 1 1 disabled - enabled
8 Auto Lock - Hardware 0 - 1 1 disabled - enabled
9 Baud Rate 0 - 4 2 0 = 9600, 1 = 19200, 2 = 38400, 3 = 57600, 4 = 115200
10 RW 485 Transmit Delay (ms) 2 - 200 10 2 - 200 milliseconds
11 Knob Push & Turn Update on Release 0 – 1 1 disabled - enabled, ignored if SPL 4 disabled.
12 Auto Page - Knob Bump 0 – 1 0 disabled - enabled
13 Knob Bump Update Timer (sec) 0 – 5 3 0 - 5 seconds, ignored if SPL 12 disabled. Knob Push & Turn updates take priority over time out.
14 Auto Title Page 0 – 1 0 disabled - enabled
15 Title Page Timer (sec) 1-25 5 1 - 25 seconds, ignored if SPL 14 disabled.
nored if both parameters 4 and 12 are disabled. For example, if this value is 3, then
only pages 1 through 3 will be selected by encoder action.
6. Knob Push & Turn Page Roll configures the action taken when the last page is dis-
played and the encoder is pushed an turned. This parameter is ignored if parameter
4 is disabled. For example, if this parameter is not ignored and enabled (a value of
1), parameter 5 is 16, and the device is currently displaying page 16, the opera-
tion of turning the encoder clockwise while it is pushed in will cause page 1 to be
displayed, the page index is updated based on the configuration of parameter 11. If
this parameter is disabled (a value of 0), then the operation of turning the encoder
clockwise while it is pushed in will have no affect in the above example.
7. Auto Level configuration affects the result of turning the encoder. If this parameter
is enabled (a value of 1), the level is updated and indicated by the LED as well. The
Auto Level configuration also affects the commands IS and ISR. See SR 3 Com-
mand Set section for details of how these commands are affected.
8. Auto Lock configuration affects the operation of the device when the lock input is
shorted to –V (hardware lock). If Auto Lock is enabled (a value of 1) and the Lock
input is shorted to -V, encoder action is locked out regardless of the software lock
status. If Auto Lock is disabled (a value of 0), the Lock input is ignored and the
encoder’s lock state is defined by the software lock status. The Auto Title Page and
Rane splash screen features are not effected by a hardware lock. The Auto Title
Page feature can defeated by disabling it (see parameter 14) or can be temporar-
